Wednesday, December 24, 2014

Vegetable garden animated GIFs!

I finally got around to making time lapsed gifs from the photos I took in the vegetable garden last spring.

Here is the side yard with squash, beans and leeks on the right and leeks and brassicas on the left. You can see the weeds are mercifully spared as the season goes on.

This is corn in the front yard.  The front variety is a popcorn and in back is Oaxacan green dent corn. The popcorn didn't grow as tall as the plants I saved the seed from but it still made some good ears.

Here is the backyard squash and tomato patch.  Some Jerusalem artichokes pop up into the frame in mid June.  You can also see some lettuce bolting just below.

I wanted to see a zucchini progressing from flower to harvest.  The first zucchini I started taking photos of got blossom end rot though.  It turned out to be a great opportunity to watch the blossom end rot process - from hopeful flower to rotten mush.  On the 7th and 8th days after the flower has closed, the end of the zucchini becomes very very faintly yellow.  Then on the 9th day it turns a striking yellow.  Each day after that the zucchini slowly rots, with a new segment rotting each day.  I tried to figure out what made the demarcation of each segment.  Was it that the rotting happened at night and stopped during the day?  Did it have to do with when I watered?  I couldn't piece it back together.  Blossom end rot happens when the fruit does not get enough calcium.  The calcium in that part of the garden though is absolutely over the top- 6754 ppm and an 82% calcium base saturation in one half of the back yard and then 5064 ppm and 69% calcium base saturation in the other half. I think what probably happened is the plants were still young at this point and I may not have been doing a great job watering the garden. (It was a big job hand watering it every day -I installed drip irrigation for this season though!)  If the soil dried out a little bit the plant might not have been able access calcium as easily as calcium enters the plants roots passively with water.   This area also tested rather high for phosphorus, 94 ppm (6.9 pH) and 163 ppm (6.6pH)!  Perhaps the calcium was locked up in slightly insoluble calcium phosphate?  I didn't see too many blossom end rot problems after the first few squash though so I think it was just a water issue.

Here's that same video slowed down starting on the 7th day after the flower closed when the zucchini just barely starts to yellow.

Lastly here's a zucchini growing like it's supposed to.

Monday, December 22, 2014

Where do we come from?

The human body is a rather complex operation.  Multiple organ systems lumbering around in a mobile casing which is home to billions of different organisms.  This intricate being is constructed using combinations of chemical elements, the building blocks of our universe.  Eleven different chemical elements make up 99.9% of the mass of a human.    So what is the source for these elements that we must absorb in order to become who we are?  For a great many of these elements it is the soil.

While volunteering for a soils education exhibit, I accosted an unfortunate visitor or two and asked them where the magnesium in their bodies came from.  Interrogating strangers on where they get their nutrients from can feel wierd. It seemed a poster with pictures would be a better way to illustrate the fact that magnesium in our bodies comes from the soil.  So then, to answer all your deep questions as to your origins:

The poster is also the work of one Jessi Barber who works for the education exhibit.  She was kind enough to replace all the photos I had just grabbed off the internet with photos her organization had taken.  She also fixed the text so it was a little more to the point.

Of the elements humans need to live, Oxygen, Carbon, and Hydrogen make up 96% of our bodies.  Nitrogen makes up another 3% which shows why it is such an important fertilizer.  Yet just because other elements represent a smaller fraction of our mass does not mean they our less important.  A human without any Phosphorus will be just as non-existent as a human without Carbon.

We get 12 of the 18 core elements we need to survive from the soil via plants and animals we eat.  Carbon, the second most abundant elements in our bodies comes from plants and animals we eat, but the source of this carbon is from the air.  Plants photosynthesize carbon dioxide and water to form sugar and then more complex carbohydrates.

Here are the primary sources of the 18 core elements that compose our body, in order of abundance by mass:

Oxygen - From water we drink and air we breathe
Carbon - From plants which take it out of the air as carbon dioxide
Hydrogen - From water we drink
Nitrogen - From plants which uptake it from SOIL
Calcium - From plants which uptake it from SOIL
Phosphorus - From plants which uptake it from SOIL
Sulfur - From plants which uptake it from SOIL
Potassium - From plants which uptake it from SOIL
Sodium - From salt
Chlorine - From salt
Magnesium - From plants which uptake it from SOIL
Iron - From plants which uptake it from SOIL
Zinc - From plants which uptake it from SOIL
Copper - From plants which uptake it from SOIL
Selenium - From plants which uptake it from SOIL
Manganese - From plants which uptake it from SOIL
Iodine - From iodized salt and sometimes from plants via soil
Molybdenum - From plants which uptake it from SOIL

Whenever plants are harvested, the elements they have absorbed into their tissues are removed from the soil on which they were grown.  These elements must be replaced in the form of fertilizers or compost otherwise the soil will become deficient in the these elements and plant growth will suffer.  Capturing these soil nutrients in our waste streams (like when we compost) is an important way to help maintain the soil fertility of our farmland.

Originally I had written, "The human body cannot survive without 16 key elements".  With this wording you're still in the right if somebody wants to tack on Bromine, Cobalt, Nickel and some other trace elements to this list.  The important thing is to not say, "The human body needs 16 elements to live, no more, no less." I've changed the poster a little to reflect 18 core elements as discussed in this blog post. If we include elements the body will use in extremely trace amounts, 36 elements have been found to play a positive role in human health. I'm sure that number will differ depending on what authority you ask and will fluctuate as new research comes out.

Even something pretty far off our radar such as Rubidium is important for the health of humans....or at least the health of "she goats": Recent progress in exploring the essentiality of the ultratrace element rubidium to the nutrition of animals and man.  Whether or not the body could survive without some of these elements and simply live in poorer health is another question.  If you want to know more about the elements required for human life check out Chapter 16. Ultratrace Minerals in Modern Nutrition in Health and Disease or the wikipedia page, Composition of the Human Body

The number of elements actually found in the human body is usually 42. For a detailed list see this table: Estimated Atomic Composition of the Lean 70-kg Male Human Body. (Somewhat worrisome for the credibility of this source is that they say there are normally 41 elements present and then list 42!)

Thankfully, if we have access to whole foods grown on fertile soils, we rarely have to think about the amount of specific elements are bodies are recieving.

Monday, December 15, 2014

Attack of the Killer Bunya Pines

I was in Aquatic Park the other day when I saw this gem:

The tree is Araucaria bidwillii, otherwise known as a bunya pine.  The tree produces male pollen cones and female seed cones.  The female seed cones can get up to a foot in diameter.  In the fall Araucaria bidwillii apparently uses the seed cones to crush hapless passersby.

A denizen of San Francisco on their smart phone, unaware they just narrowly survived an encounter with the killer Araucaria bidwillii

Lead contamination for the home gardener

I've been wanting to write this post for some time as this is an issue that has come up a lot for me - What does one do if their soil is contaminated with lead (and they happen to be helplessly obsessed with vegetable gardening)?  It can be hard for home gardeners to make an informed decision as to the safety of their yard for cultivation.  Figuring out specific vegetable species to avoid is also difficult to find information about.  I hope this post can be a resource for home gardeners on the following:

1. How to figure out if you have lead in your soil

2. Just how much lead is too much lead

3. What vegetable species should be avoided

4. What can be done to mitigate lead contamination

For the sake of all you busy, hard working folk out there who just want to get to the facts without the explanations, the most important points are in bold.

1. How to figure out if you have lead in your soil

Send a soil sample to UMass Soil Testing Laboratory and order a "routine test" with "organic matter":

A simple soil test which can cost as little as $15 can tell you the levels of lead in your soil.  There are many laboratories which will analyze your soil for lead, but the best option in my opinion is the UMass Soil lab.  They have always been quick, they are inexpensive, and it's a relatively simple process to send them your sample.

In order to have your soil analyzed by UMass you will first need to collect soil samples.  You can have the lab analyze multiple samples at a time which will allow you to divide your yard into sections you can test individually.   This can really help you pinpoint which areas of your yard have lead contamination, as it may only be a certain portion.  Say for example you suspect your backyard is contaminated but that your front yard is fine, it would be best in this circumstance to test these areas separately. It's important to note that the soil within three feet of a house that had exterior lead paint generally has a much higher lead content than other parts of a home garden.  Take this into account when sampling.  You might want to do one sample around the perimeter of the house, and have your other samples not include this area.

Umass has guidelines for how to properly collect your soil samples here: Sampling Instructions.  You're basically going to use a clean shovel to collect soil from at least 12 random spots in your sample area. The soil is collected from a depth of 6-8 inches.  I generally put the soil directly into a ziplock bag.  You can also use a bucket or any other container.  You need the sum of your samples to be at least a cup worth of soil.  Try to avoid getting roots or other large pieces of biomass in your sample.  Before you send in your sampple you have to let the soil dry out before you ship it. It will distort some of the nutrient tests if you seal a bag of soil when it is wet.  I sometimes spread the soil out on a clean baking pan and put it in an oven at the lowest temperature possible to hasten the drying.

Once your soil sample is dry, mix it well and then place it in a ziplock bag which is labeled with the area you sampled from.  Try to use a clean shovel or other instrument rather than touching the soil with your hands.

Print out this order form from Umass for a basic soil test.  The basic test will tell you many metrics in addition to lead.  This includes: pH, exchangeable acidity, extractable nutrients (P, K, Ca, Mg, Fe, Mn, Zn, Cu, B,  S), extractable lead (Pb), extractable aluminum (Al), cation exchange capacity, and base saturation.  Don't worry if you don't understand what all of those mean, they are not that complicated!  Knowing your soil organic matter levels in addtion to these metrics can be helpful when it comes to mitigating the risks of lead contamination.  For this reason it's a good idea to opt for the $6 organic matter test as well on the order form.

Place your completed order form, your labeled samples in ziplock bags and a check into one of the small boxes available at your local post office.  Then send the package off to the UMass lab.  The results should be emailed to you in under a month.

2. Just how much lead is too much lead for home vegetable gardening.

If you have anything over 100 ppm you should inform yourself about how to minimize the risk of lead exposure from home vegetable gardening.  If closer to 400 ppm you should definitely be taking steps to reduce lead bioavailability and use mulch, additional soil and possibly raised beds to limit contact with contaminated soil.  You should also be selective as to which crops you grow.  Cultivating directly in soil with lead over 400 ppm is a bad idea.

Exposure to lead is a dangerous health risk, especially to children.  Take soil lead contamintaion seriously.

Once you've reached this step you should have some test results that show you the levels of lead in your soil.  The information you are looking for is total estimated lead.  Extracted lead is merely the amount of lead that can be measured by the testing procedure.  Total estimated lead though extrapolates from the extracted lead measurement to tell you the actual amount of lead you have in your soil.  The measurement will either be in ppm (parts per million) or mg/kg (milligrams per kilogram).  These are both the same measurement as there are one million milligrams in a kilogram.  If your test only shows extracted lead here is a table (from the very useful UMass Lead testing and recommendations page) to find out the total estimated lead in your soil:

Lead LevelExtracted LeadEstimated Total Lead
--------------------------------- mg/kg or ppm ---------------------------------
Low        less than 22            less than 299
Medium        22 to 126            300 to 999
High        127 to 293            1000 to 2000
Very High        greater than 293            greater than 2000

Natural levels of lead in soils range from 10 - 50 ppm.  The EPA says that children should not be exposed to bare soil with levels higher than 400 ppm. The danger with bare soil is that children might ingest this soil or breath in dust from the contaminated soil.  At 400 ppm, eating only 1/4 teaspoon of soil per week would put children 6 years or younger over the threshold of safe lead blood levels.  The EPA has deemed soils with lead levels higher than 1200 ppm unsafe for all humans.  Some states are more strict than the EPA.  The University of Massachusetts says 300 ppm is the point at which children and pregnant women should avoid contact with bare soil. Minnesota is even more stringent with a limit of 100 ppm for bare soil where children are present.

So we know that if people are going to be inhaling dust or ingesting soil, 400 ppm is certainly too high for children and pregnant women and 1200 ppm is too high for adults. But how much lead is too much if one wants to grow vegetables?  If growing vegetables entails kicking up lots of dirt and inhaling dust than anything near 400 ppm is too much.  Likewise if one grows root crops that are not peeled or have soil residue on them, than anything near 400 ppm is too much.  Growing vegetables which are prone to absorb lead means that 400 ppm is again too much.  So there are a lot of reasons why it's best to only cultivate if soil lead levels are under 400 ppm.

There are other factors at play though when evaluating the risk of growing vegetables in soils with slight lead contamination. Two soils with the same amount of lead might pose very different levels of risk.  The two main variables are the bioavailability of the lead in your soil and the species of vegetable you are growing. If one's soil has a high pH, with high levels of organic matter and phosphate, then the lead is less bioavailable and there is a lower risk for lead uptake into vegetables.  Avoiding species of vegetables which uptake more lead than others will also lower ones risk.

In a study I will link to below, tomatoes grown in soil with 3470 ppm lead (ridiculously high) had undetectable levels of lead in their fruits.  However the leaf tissue on these plants had 22 ppm lead and the root tissue 715 ppm.  I wanted to use this tomatoe to illustrate that technically you could grow something in a very contaminated soil and because you were selective about the species you were cultivating you would technically be ok.  Personally I would feel like a little leery eating those tomatoes.

Although we have shown a case where tomatoes did not pose a threat to human health in 3470 ppm lead, swiss chard in soil with 910 ppm lead had 24 ppm lead in the leafy parts of the plant we eat.  We can note here that the swiss chard and tomato leaf tissue had a similar amount of lead, but the difference between these two scenarios is that we eat the fruit of the tomato, not the leaf tissue, and the tomato was grown in soil with over three times the amount of lead.

So we're beginning to see why it's hard to come up with a single number at which point crops become unsafe: Different plants uptake different amounts of lead.  In addition, depending on the plant we'll eat the roots, the leaves or the fruit. Root tissue is more likely to contain lead, followed by leaves and then fruit.

The other variable that makes it hard to declare a specific ppm of lead unsuitable for vegetables is bioavailability. Depending on your soil there are different levels of lead "sorption"- this is when the lead is bound to clays or organic matter in the soil and is not available to the plants. The more organic matter (and certain clays) your soil has the more chances there are to lock up lead.  The higher the pH, the more sites there are on clays and organic matter for lead to be locked up and made unavailable.  If a soil has a low pH of 3 or 4 lead is very very bioavailable for plants to pick up.  Of course, if your soil pH is 3 you probably won't be able to grow much of anything in the first place!  But at a pH of 5.8 you could still grow vegetables and your plants would uptake more lead than if your soil pH was 7.

Given all the different variables at play here, it can be hard to know if a soil is safe for growing vegetables solely based on the measure of estimated total lead.  Certainly if a soil has 3,000 ppm lead we know this soil is dangerous to work with.  But if your soil has only slightly elevated levels of lead, say 200 ppm, the following variables play a large role in deciding if soil is safe to cultivate:
-What crops you are growing
-The bioavailability of lead to plants
-If you are exposed to large amounts of dust

If you have over 100 ppm, you can do several things to minimize your risk.  Check out parts 3 and 4 for more informaiton.

3. What vegetable species should be avoided.

Cilantro, Mint, Lemon balm, Epazote, Rhubarb, Swiss Chard, Beets, Mangels, Good King Henry, Orach, Spinach, Carrots, Radish, Onions, Garlic, Leeks, Potatoes, and Turnips should not be cultivated on soil with mild lead contamination.  These vegetables are more likely to absorb lead into edible portions.

Root vegetables in general have higher levels of lead than leafy vegetables.  Leafy vegetables generally have higher levels of lead than fruiting vegetables.

Root crops in general are problematic for two reasons.  First, unless they are peeled, it is difficult to fully cleanse them of soil (which in our scenarios contains lead).  Second, plants grown on soils with lead tend to have much more lead in their root tissues than in their shoot tissue or fruits.

Leafy greens are safer than root crops as leaf tissues have lower amounts of lead than a plant's root tissue. However if rain, watering, or dust gets contaminated soil on leaves this is a pathway to lead exposure.

The safest type of vegetables to eat are those with fruiting bodies. Plants move very very little lead into fruiting bodies.  These include peppers, eggplants, tomatoes, squash, melons, grapes, berries and tree fruits.  Grains such as corn, wheat, rye, barley, oats, also have a low chance of receiving lead from the plants they grow on.

What about specific species though?  There are some plants which have a tendency to uptake much more lead than others.  This article, Lead levels of edibles grown in contaminated residential soils: a field survey, is a great resource which examines levels of lead absorption in different types of vegetable.  From the results of this survey, the following vegetables should be avoided when cultivating on lead contaminated soil:

Cilantro, Mint, Rhubarb, Lemon balm, Epazote, Swiss Chard (and by extension Beets and Mangels, which are the same species), Carrots, Radish, and Onions

Potatoes were not included in this study but other members of the genus Solanum had high root concentrations of lead so it would probably be best to avoid this crop as well.

Turnip was also not included but other members of the same genus contained high levels of root tissue lead.

Spinach, Good King Henry, and Orach are closely related to Swiss Chard and Epazote so they would seem to have a high chance of heavy lead uptake.

Leeks, Garlics, Chives and other members of the genus Allium should be avoided as another member of this genus, Onion, was shown to readily uptake lead into the edible part of the plant.

There was one instance of cucumbers having high levels of lead, although cucumbers from six other contaminated plots had undetectable levels in the fruiting body.  I have not added this to the list of plants to avoid.

Two members of the Lamiaceae family, Lemon Balm and Mint, seem to easily uptake lead, but another member, Basil did not.  As such it is hard to predict how other Lamiaceae herbs like Oregano, Thyme and Sage would uptake lead. The Basil which did not uptake detectable levels of lead in the study was only in 280 ppm lead so perhaps at higher levels it would behave more like Lemon Balm and Mint.

Unfortunately this field survey leaves out a number of different vegetables and food crops. It would also have been nice to see the pH and organic matter content of the soils to get an idea of the lead bioavailability the plants were exposed to. The survey is the most informative article I have seen on rates of lead absorption in different vegetables though. By reading the article you can see which types of vegetables are indeed safer for growing on mildly contaminated soils.

4. What can be done to mitigate lead contamination.

Take steps to minimize contact with soil such as laying down mulch or a new layer of soil, and prevent dust inhalation by keeping the soil moist.  Adding phosphorus, organic matter and raising the pH of your soil will decrease the bioavailability of lead to vegetable plants.  For soils with over 400 ppm consider growing in raised beds with bottoms that roots cannot penetrate.

The University of Massachussetts has a great webpage on soil lead with a helpful section on Good Gardening Practices to Reduce Lead Exposure.  If you have lead contamination it's definitely worth checking out their recommendations.

Other great resources can be found here:
Lead in Garden Soils
Lead Contaminated Soils: Minimizing Risks
Gardening on Lead and Arsenic Contaminated soils

There are two ways that the home gardener should aim to minimize exposure to lead: reducing physical contact with contaminated soil and reducing bioavailability of lead to vegetables.

Reducing phycical contact with contaminated soil simply entails putting a barrier between yourself and the soil.  You can acheive this by laying down landscaping fabric, mulch, or new soil on top of the contaminated soil.  If you want to cultivate the soil and there is less than 400 ppm in the soil, what I prefer to do is bring in a few cubic yards of compost and raise the soil level a a few inches. You should also try not to work with the soil when it is extremely dry to prevent dust inhalation.

Reducing bioavailability to vegetables involves three parts: raising soil pH to 7, raising levels of soil organic matter, and adding phosphorus.  The higher the pH, the more lead is bound to certain clays and organic matter, making it less likely plants will take up the lead.  To increase soil pH, add a liming agent like calcium carbonate  or calcium magnesium carbonate (also known as lime and dolomite lime).

Phosphorus in soil will bind with available lead to form lead phosphate, which has very low solubility and is unlikely to be absorbed by plants.  Rock phosphate, bone meal and fish emulsion are usually good sources of phosphorus.  I prefer fertilizers that will break down and release their nutrition gradually.  This decreases losses to leaching.  Pollution of groundwater from excess phopsphorus fertilizer is a serious problem so don't over apply.  If you're soil test shows that you have more than 50 ppm phosphorus you should not apply any additional phosphorus fertilizer.

Lastly aim to get your organic matter levels to 4 or 5%.  Not only will you be immobilizing soil lead, but you will also have an extremely healthy and productive soil once you hit this level of organic matter.  Add manures, organic fertilizers and, most importantly, compost to your soil and your organic matter levels will slowly rise.

Lead is a naturally occuring element in soils.  Often times in urban settings soil lead levels become more elevated than naturally occuring levels.  This can pose a health risk to those wishing to cultivate vegetables.  Keep in mind the following points though and you should be safe:

Don't cultivate on soil with over 400 ppm
Pay close attention to the different types of vegetables that you should not grow (Part 3.)
Take steps to minimize contact with the contaminated layers of soil and reduce lead bioavailability (Part 4.)


If you happened to have eaten vegetables grown on soil with heavy lead contamination or toiled in contaminated soil (I've done both- a lot!)  all is not lost.

First, if you think your child have been exposed to high levels of lead, a simple test can be performed to determine the level of lead in their blood.  Contact your primary physician for more information.

If you're like me and you think you've probably come in contact with lead through your gardening activities there are several ways you might be able to reduce the levels of lead in your body. Eating cilantro has been shown to chelate and remove lead from the body in some studies, while other studies show that it at least protects the body from absorbing lead.  If you recall from Part 3, cilantro was a plant to avoid cultivating due to it's propensity to absorb lead.  Interestingly, of all the plants surveyed in the article I linked to, cilantro had the highest ratio of shoot tissue to root tissue lead, 1:1.6.  In addition to cilantro, chlorella has been shown to help the body eliminate mercury and other heavy metals.

Other than cilantro and chlorella, there are several other foods which are being examined for their ability to help the body eliminate heavy metals.  Just eating healthy is a good start though as research shows that a diet high in vitamins and minerals can help protect against lead absorption.  There are very powerful pharmaceutical chelating agents (EDTA, DMSA etc.) which can be used to remove lead from the human body, but these are not without side affects since they can remove many important elements from the body such as magnesium in addition to heavy metals.

If you're interested in reading the studies yourself, below you'll find various journal articles on foods which support heavy metals elimination.

Studies which examine the role of cilantro in absorption and elimination of heavy metals:

Preventive effect of Coriandrum sativum (Chinese parsley) on localized lead deposition in ICR mice.

Significant mercury deposits in internal organs following the removal of dental amalgam, & development of pre-cancer on the gingiva and the sides of the tongue and their represented organs as a result of inadvertent exposure to strong curing light (used to solidify synthetic dental filling material) & effective treatment: a clinical case report, along with organ representation areas for each tooth.

Effect of cilantro on plasma lead levels and some hematological parameters in rats

Effect of Coriandrum Sativum L. extract on blood and urine lead concentrations in 3-7 year old children
In this study, although blood and urine lead concentrations decreased in children given cilantro extract, similar results occured in children given a placebo. This study of course casts some doubt on cilantro's use in eliminating heavy metals.  The conclusion reads as follows: " According to the results of this study, it seems that Coriandrum Sativum is not effective in lead elimination. Increasing renal lead elimination in both groups of children may be due to other factors like improvement of
nutrition following the education at the beginning of this study."

A study which examines the role of Chlorella in eliminating methylmercury:

Enhanced elimination of tissue methylmercury in Parachlorella beijerinckii-fed mice

Studies examining the role of different vitamins and minerals in heavy metals absorption and elimination:

Intake of magnesium and toxicity of lead: an experimental model

Maternal Blood Lead Concentration, Diet During Pregnancy, and Anthropometry Predict Neonatal Blood Lead in a Socioeconomically Disadvantaged Population

Effects of Micronutrients on Metal Toxicity

Selection of Nutrients for Prevention or Amelioration of Lead-Induced Learning and Memory Impairment in Rats

Preventive and therapeutic role of vitamin E in chronic plumbism

Beneficial effect of combined administration of some naturally occurring antioxidants (vitamins) and thiol chelators in the treatment of chronic lead intoxication

Vitamin C modulates lead excretion in rats.

Lastly, here's a review (that I wish I had found much earlier!) which gives a brief overview of the current research on heavy metals absorption and elimination using different foods and pharmaceuticals:

Chelation: Harnessing and Enhancing Heavy Metal Detoxification—A Review

It's important to remember what this research is NOT saying.  Don't think that because you eat cilantro every now and then, you now have a license to work in 1,000 ppm lead soil.  Stay safe when you're vegetable gardening and make sure you understand the lead situation in your soil.

I hope this post helped answer some questions you might have had about growing vegetables in soil with lead.  If you have further questions, feel free to post a comment!

Monday, November 10, 2014

Photos of the Fankanta demonstration farm

The Fankanta demonstration farm is a place where people can come and learn how to grow food without needing to use hybrid seeds, chemical fertilizers, or pesticides.  Fankanta literally means "prepare yourself" and it is here where people can learn to become more self reliant - to grow food without needing to purchase inputs.  We've all worked extremely hard at Fankanta to get the plants growing well and I wanted to use this post as a photo gallery to show some of the beautiful crops at the demonstration farm.

A bed of Clemson Spineless okra

Upland rice

Okra and corn planted by people who had come to the center for training

Mint in various stages of growing back after being cut. To the right is corn.

Mint with corn behind it

A row of newly planted moringa saplings to the left with corn on the right.

Cucucmbers, corn, watermelons, and bunching onions are all visible in this picture.  We were experimenting with trellising for some of the cucumbers.

Compost windrows from our compost program.

View from up high of the farm.  The foreground is filled with very young citrus, sugar apples, sapoteys, coconuts, and moringa.  There are also some older citrus, mangoes and bananas visible.  In 5 years time or so the area should be a dense orchard.  The annual crops are in beds both in the visible background and behind the trees on the left.

Tuesday, October 21, 2014

Fundraising campaign is up and running

A few days a go we launched a fundraising campaign to support the compost program we've been running, to pay for a new pump, and to expand the Fankanta Agroecology Center's training operations.  If you'd like to watch a little video to learn more about the composting program (or even donate!) you can visit the campaign at

Here's an update which I also just posted onto our indiegogo page about what has been happening lately at Fankanta.

The organic waste keeps coming in by the cartload.  We recently started a third windrow.  Here is Gabu, in front of Lat Dior the horse as his father Mr. Diouf unloads the day's delivery.

You can see in this picture we're just starting the new windrow.  In the foreground is a recently turned windrow and in the background on the right is part of another windrow.

Three weeks ago we had a meeting with a group of citizens concerned about the state of the environment in Keur Massar, the community where we are located.
The very next day several community members came by to learn about sustainable farming methods.
Three weeks later we usually have a few community members coming by every day to learn about how to farm without needing to buy expensive inputs.
Today, Mr. Ndyere and Mr. Ndyalo cleared a bed to plant corn.  Mr. Ndyere raises chickens and Mr. Ndyalo is a market farmer who is growing mostly peppers and cabbage at this point.  They are both interested in learning new farming techniques and have been coming by the Fankanta agroecology center several times a week.
Here the bed is being moistened in preparation for the corn.  Two other communty members who have small farms are helping out.
Yesterday Mr. Chendou planted out this nice bed of corn:

On Saturday we were at the 2014 Africa Social Forum where Lamine was on a panel discussing the role of youth groups in education, skills training and youth development.  Lamine talked about a boy/girl scout trade school and how the Fankanta Agroecology center is training youth in sustainable farming.  Youth unemployment is a problem here in Senegal but with trade schools and programs designed to give people the skills they need to be market farmers, youth groups are working to address the issue.
After the Africa Social Forum we also attended a Scouts meeting to discuss the results of a program where a dilapidated building was restored and compost training courses were given.
Between running the demonstration farm, the composting program, training visitors to the demonstartion farm, and going to various meetings we have been very busy!  With your support of our fundraising campaign though, we will be able to develop our young organization and demonstration farm into an even more important community resource.
A last note about market farming in Senegal.  The last blog post recounted how we sold 120 kilos of radish for 4800 CFA Francs.  Well just today we finished selling a mere two beds of mint for 5000 CFA Francs!  This mint was only transplanted from cuttings about a month ago.  If it was a more mature planting with denser foliage the two beds could have sold at 10,000 Francs.  At $20 USD, that's an extremely lucrative proposition here.  It goes to show that the Senegalese like their mint tea and mint is not as easy to grow in the Sahel as it is in the temperate US. Here's Lamine with the bana bana market woman cutting the mint bed.
Stay tuned - I'll hopefully have an update soon about the crops and trees we're growing at the Fankanta demonstration farm.

Thursday, October 2, 2014

Big Money and the Bana Banas

So, you want know how to rake in a cool 4,800 CFA? Radishes, that's how. (Do yourself a favor and don't worry about the exchange rate there.)  Market farmers on the periphery of Dakar generally don't sell their produce themselves.  Instead bana banas, market women, come to the farms, buy what they think they can sell, and bring that produce to market.  Bana bana is the Wolof term for any small retail vendor, vegetable sellers included.
Last week a group of bana banas came by the Fankanta agroecology center.  They asked me, "Do you have any... " and then said something in wolof which meant absolutely nothing to me.  "No", I replied, "but we do have radishes!"

In fact we had several hundred kilos of radishes in the ground and ready to be harvested.  Now radishes are great and all, but it's hard to get excited about eating your way through even ten kilos.  I was so very happen then, that the bana banas wanted to take them off our hands.  The women even wanted to buy the whole crop - perfect.

The women went through and picked the radishes they deemed acceptable.  They ended up pulling out 150 kg.  Afterwards they crammmed an impressive amount into buckets which they carry off on their heads.  The rest they stuffed into sacks and hauled out on a donkey cart.  In all I estimate they actually ended up taking around 120 kg.

Sometimes the radish market is up and sometimes it's down.  If you went ahead and converted the CFA to USD like I told you not to you know where the market is now!  This brings to mind the following Mitchell and Webb Situation sketch that one Mr. Brett Blake showed me years ago.  A note of caution to our more respectable readers; there is a swear word!

In other exciting news, the organization I'm working with is now online! It's a bit like the death star in Return of the Jedi - still under construction yet fully operational.  Check it out. If you don't like to read, there are pictures!

Check back in next week and I'll have an important announcement for you.  Thanks for stopping by.

Saturday, September 27, 2014


Last weekend at the demonstration farm we were joined by a "patrol" of Senegalese eclaireurs - boy and girl scouts!  Here in Senegal there is actually no distinction made between boy and girl scouts, they are all simply referred to as scouts or eclaireurs and both girls and boys participate in the same group.  This troop had traveled from the other end of Dakar to camp out, sing songs, and learn about sustainable agriculture.  Although I made it all the way to webelos, I never did make it out of cub scouts into the much more honorable world of boy scouts.  I'm pretty sure though that scouts in the US do not have the same awesome repertoire of camp songs as this troop.  Most of them were in Wolof so I have no idea what they were about, but for every activity it seemed they had a song to passionately belt out.

Here's the group singing a number beneath the Senegelese and scouting flags.

 Their second day at the center the Scouts got to work on the farm. Here they are clearing out an area of weeds to prepare the soil for planting.  If you look closely, you can see one of the scouts on the right holding the ilere tool I talked about in the last post.
Below are two hard working scouts double digging the soil.  Preparing the soil to a depth of 2 feet aerates the soil and gives roots lots of room to access water and nutrients.

The troop ended up planting out two beds of Okra.  Clemson Spineless, Burgundy Red, and Cajun Jewel were the varieties we had started as seedlings for them.  The work really goes fast when you have such a large group all working together.

Here Fatou (in the gray t-shirt) is giving the scouts instructions on watering in their newly planted okra seedlings.  Together, Lamine and Fatou run the Fankanta demonstration farm in addition to co-ordinating the other aspects of the Oasis Grow Biointensive Association.  On the left hand side of the picture you can see that some neighbors were interested to see the team planting out their okra and came by to watch.

And here is the proud patrol of Senegalese scouts posing in front of their handiwork.  Lamine is actually the commissaire général of scouting in Senegal, in other words, the top scout in the entire country.  He has been able to introduce sustainable, low input farming to a lot of youth this way.  For most of their stay the scouts were on their own under the leadership of the camp cheif, the tall scout in the middle.  I have to say I was rather impressed by how self sufficient they were when it came to making their own fire, cooking, and carrying on with their camp activities.

Thanks for the help eclaireurs du Senegal!

Tuesday, September 16, 2014

Upland rice / Progress on composting project

Two weeks ago at the Fankanta demonstration farm we were busy planting out a large swath in upland rice.  Upland rice is rice that does not need to be grown in a flooded paddy.  This particular variety comes from further south in Senegal.  One of the association members brought back some seed from his mother's village.  Apparently farmers in this village still have not come into contact with urea fertilizer. Instead these farmers use mostly animal manure. I was told though that there is no horse manure as tsetse flies in this region transmit nagana (a parasite) which kills horses.
Luckily there are no tsetse flies this far north in Senegal!

Below you can see the beds just before the rice was planted, and then two weeks later.

Here is Sadibou using an ilere, a combination shovel/hoe to make ridges (pints in Wolof) around all the beds.  You could say it is the spork of farming tools.  Though at first, using it was a bit like trying to eat with chopsticks for the first time.  The metal blade can be used to move small amounts of soil when held as in the picture.  But, if the ilere is held further toward the end of its handle, it can be pushed back and forth across the ground, cutting weeds down in the sandy soil.

 As water is very precious here most farmers grow in beds that have raised ridges like Sadibou is making here. This ensures that water stays in the beds and does not run off into the pathways.  Watering here is done almost exclusively with watering cans which can take quite a long time.  This is another reason why it's helpful to make sure the water stays in the bed.  The less water that runs off into the pathways the less one has to walk back and forth to the well with their watering cans.

Rice is a staple of the Senegalese diet yet most of it is imported from India, Thailand, or South America.  Lamine is hoping to show that local rice production is feasible and worthwhile with the organic upland rice we are growing.  Below you can see an example of one of the 50 kg sacs the rice comes in.  Every bag of rice I have seen so far and every meal I have eaten has been "Brissures de riz" or broken rice peices.

Our community composting program just started up last week.  Right now we're just targeting the local market.  Each day a horse cart brings the food scraps from the market to the demonstration farm.  Here is Lamine painting the initials of the Association Grow Biointensif onto the container we provide the market.

The pile is getting bigger every day.  Right now it ranges between 115 and 125 degrees F depending on how old the scraps are.  We're excited about getting some finished product out to farmers.  The soil here is extremely sandy and this compost could do wonders for soil fertility and moisture retention.  Farmers here rely heavily on urea fertilizer and pesticides. Urea is certainly effective at delivering nitrogen to plants, but there are many other nutrients that plants need and over time the urea acidifies the soil. It becomes a cycle where the plants recieve poor nutrition, they become more susceptible to pest pressures as a result, and then farmers are forced to use pesticides and fungicides which further damage soil health and the ability of plants to access the nutrients they need.  People here are curious about alternatives to urea and pesticides though.  Cow and chicken manure is definitely in use, but I'm hoping that the compost will prove to be a more easily accesible resource in addition to being more beneficial to soil health.

Sunday, September 14, 2014

Chocolate pudding fruit, plant stimulants and a pepper puzzler

The Association Grow Biointensif had a meeting this past Saturday at one of the member's farms to discuss their current programs.  We sat under the canopy of an amazing orchard filled with fruits I had never even heard of.  In fact there are enough intriguing edible and medicinal plants here to fill up several dozen blog entries.

This interesting fellow is Diospyros nigra.  The genus Diospyros also contains asian persimmons and means divine fruit in Greek. Here people call it sapote although in the other parts of the world it's known as black sapote to differentiate it from the unrelated mamey sapote and white sapote.

The tree gets quite large as you can see below.  This one was planted in the late 1990s and should grow even taller.

The fruits on this one weren't ready but I've been told they have the consistency and flavor of chocolate pudding.  Apparently there in the markets right now but I've been too fixated on mangos and haven't branched out.  Getting my hands on one of these chocolate pudding fruits is a new priority now.

Another common plant around here is thiakhate (chyakhat is what it sounds like although I'm terrible at pronouncing it correctly).  You can see this vine crawling along the ground as well as climbing trees.  The entire plant is used to brew tea and the leaves are often eaten in local dishses. I was told it can help combat fatigue and is used to treat various ailments.  It's hard work here at the demonstration farm so I started drinking quite a bit.  Since yesterday I've probably had about two litres of thick thiakhate tea.  I have to say I feel pretty good as of late, although I can't be sure it's from the thiakhate.

After much suffering, tonight I figured out that the binomial name is Leptadenia hastata.  This paper by Steven D. Thomas, Leptadenia hastata: A Review of its Traditional uses and its Pharmacological Activity, shows that there is indeed something happening when one drinks a nice warm glass of thiakate.  The plant has been shown to have anti-microbial, anti-inflammatory and anti-androgenic properties.  That last one might have something to do with this vague sense of vitality I've been feeling.  It could also just be that I ran to the demonstartion farm the past two mornings.

Outside of the orchard, there was also a large plot of peppers that were clearly suffering.  The grower asked me what the problem was and there I was in the hot seat! I said it might be an immobile nutrient deficiency or a virus but I would research it some more. If you have any ideas what's going on I'd love to hear them.  I'll walk you through what I thought was going on (this is might be really boring if you're not into plant nutrition).

As you can see, the new growth is curled and the leaves are rumpled. It looks like maybe an immobile nutrient could be deficient as the new growth is the worst off. The whole plant seems to have rumpled leaves though. Since the young leaves are curled in on themselves it seems like it could be a calcium problem.

Later, the farmer showed us his supply of wood ash. He was very proud to be using an organic fertilizer and had stockpiled an enormous quanitity of it. I imagine they were using quite a bit on the farm.

Wood ash contains a fair amount of potassium and calcium, so if they were heavily applying this to the soil it seems unlikely calcium would be deficient.

The picture below though shows what looks like soft intervenal chlorosis on the newer leaves. Could it be manganese? This "soil" was extremely sandy, and the cation exchange capacity was probably quite low. Sand only has a CEC of about 5, Maybe all the potassium and calcium that was added was hogging the exchange sites and preventing the uptake of manganese.  Wood ash also raises the pH of the soil. This would seriously decrease manganese ability if the pH went much above 7.  I have also read that manganese affects plants ability to properly utilize calcium, which could explain the first picture.  So this is one theory.

There seemed to be an epicenter to this issue where some plants had already died and some looked like this.  Possibly a spot where more wood ash was dumped than other places?

I'm not really sure what this variety of pepper is supposed to look like but here are the fruits.

Having a basic ten dollar soil test that showed the pH, cation exchange capacity, and nutrient levels would be really useful for this type of puzzler.  Unfortunately that's just not available here.  For some reason I always want to see every problem as a nutrient issue, maybe because that means there's a straightforward solution to the problem.  With these peppers though the issue could just as likely be a virus. Given the mottled yellow coloring and the twisting leaves a virus might be a better candidate for what's going on.  It could also be a mite problem and I just couldn't see the mites.  So I'm going to say either manganese, a virus, or mites.  That's probably not going to be a very satisfying answer.  Let me know if you have any ideas!

Picture of Cassava re John Beeby's comment
